technique solution
solution ：
1. products processing solution
1) customer: 2) product: clutch pressure plate； 3） material: fn-0205-25;
4) the product profile
5) machining accuracy: completely follow up the customer’s drawing;
6) work tool and fixture: 6 inch hydraulic chuck
7) the technique remarks: the program will set up the tools life-time management (customer pre-set up the q’ty of the machining products, when reach it, automatically warning, for reducing the products scraps and the tools damage.)
gongtie company will do the best to provide the technique guidance for cnc lathes and related suggestion of the products processing technology.
8) proposal cnc lathe：
precise linear guide-way cnc lathe with slant base body in t-slot blade row : s36
s36 lathe feature: high precision, high efficiency, heavy cutting, best cost-competitive
*with 45º body base design, and excellent resin sand, die-casting for integral bed body, strict thermal aging treatment, to make sure the high stiffness.
* high precision and sleeve-style independent spindle structure, and high speed hydraulic swing system, to guarantee the high rotating speed.
* high precision and enhanced linear guideway and ballscrew, with central and pre-stretching ballscrew assembly method, for realizing the precise turning with tolerance of µ level.
* reasonable layout, large internal space, fashionable appearance design.
9) machining process proposal:
|
op10the workpiece clamping & turning sketch for the first process |
|||||
|
6 inch chuck in the outside clamping way |
|||||
|
process |
tool |
speed |
feed |
machining time(s) |
|
|
od,chamfer(rough machining) |
|
800 |
0.08-0.1 |
≈4.5s |
1.5s |
|
id(rough machining) |
|
800 |
0.08 |
≈14.5s |
1.5s |
|
od,chamfer(rough machining) |
|
1000 |
0.07 |
≈5s |
1.5s |
|
id(rough machining) |
|
1000 |
0.06 |
≈15s |
1.5s |
|
total machining time |
45s |
||||
|
op20the workpiece clamping & turning sketch for the second process |
|||||
|
in the outside clamping way for od φ223.6 |
|||||
|
process |
tool |
speed |
feed |
machining time(s) |
|
|
id(rough machining) |
|
800 |
0.08 |
≈13s |
1.5s |
|
id(finish machining) |
|
1000 |
0.06 |
≈14s |
1.5s |
|
total machining time |
30s |
||||
10) cnc lathe sketch:
10.1) precise linear guide-way cnc lathe with slant base body in t-slot blade row : s36
10.2> rigid base
2. parameters, configuration and price:
1) parameters:
|
main parameters |
unit |
s36 |
||
|
processing capability |
max. swing diameter |
mm |
φ300 |
|
|
max. turning diameter |
mm |
φ120 |
||
|
max. turning length |
mm |
φ330 |
||
|
max. bar through-hole |
mm |
26(35) |
||
|
spindle |
work piece clamping method |
n/a |
6“hydraulic chuck |
|
|
spindle speed range |
rpm |
0～5000 |
||
|
spindle nose size |
n/a |
a2-5 |
||
|
spindle id |
mm |
48 |
||
|
spindle structure |
three bearings before, two bearings after |
|||
|
rapid traverse |
x-axis/z -axis |
m/min |
20 |
|
|
axis stroke |
x-axis travel |
mm |
420 |
|
|
z-axis travel |
mm |
330 |
||
|
accuracy |
x\z axis repeating positioning accuracy |
mm |
0.002 |
|
|
motor |
spindle drive motor |
kw |
3.7/5.5 |
|
|
others |
tool-holder type |
n/a |
t-slot blade row |
|
|
tool size |
mm |
16 |
||
|
min. feeding |
mm |
0.01 |
||
|
required electric power |
kva |
8 |
||
|
overall size(l*w*h) |
mm |
1850*1750*1750 |
||
|
height from floor to spindle center |
mm |
≈1070 |
||
|
net weight |
kg |
≈2400 |
||
|
standard: tool box, instruction book, operational manual, lighting system, lubrication system, hydraulic collet(chuck),
|
||||
|
optional: program control blowing function, precision c axis dividing,spindle head , automatic door, loading and unloading system, industrial robotic,automatic bar feeder, receiving device for bar materials, automatic detection system, automatic cutter radius compensation system, chips cleaner, high-pressure cooling system, foot switch, |
||||
2) configuration and price
|
cnc lathe |
||||
|
no. |
item |
component brand & spec. |
original countery |
qty. |
|
1 |
controller |
syntec 21ta |
taiwan |
1 |
|
2 |
x/z axis servo motor/drive |
yaskawa 850w |
japan |
2 |
|
3 |
spindle motor |
syntec 3.7/5.5 |
taiwan |
1 |
|
4 |
ball screw & linear guide-way |
pmi, 0.008 |
taiwan |
2，4 |
|
5 |
spindle bearings |
ntn p4 |
japan |
5 |
|
6 |
spindle structure |
independent spindle with front three bearings and two after |
by gongtie |
1 |
|
7 |
ball screw supporting method |
doublesupporting with pre-stretching structure |
by gongtie |
1 |
|
8 |
hollow hydraulic rotary cylinder |
536 |
taiwan components |
1 |
|
9 |
hydraulic system |
huizong |
taiwan components |
1 |
