technique solution
1.solution ：
1) customer: ； 2) product: ； 3） material: ;
|
4) the product profile |
5、machining accuracy: completely follow up the customer’s drawing;
6、work tool and fixture: precision customized 6 inch power chuck
7、the technique remarks: the program will set up the tools life-time management (customer
pre-set up the q’ty of the machining products, when reach it, automatically warning, for
reducing the products scraps and the tools damage.)
|
the workpiece clamping & turning sketch for the first process |
|||||
|
process |
tool |
speed |
feed |
machining time(s) |
|
|
od,face,chamfer |
|
s2200 |
f0.07 |
≈21.5 |
1s |
|
finish machining |
|
s3200 |
f0.08 |
≈11.5 |
0.5 |
|
drilling |
|
s2000 |
f0.06 |
≈6 |
1 |
|
tapping |
|
s1600 |
f0.06 |
≈3 |
1 |
|
total ≈48.5s |
|||||
|
the workpiece clamping & turning sketch for the second process |
|||||
|
process |
tool |
speed |
feed |
machining time(s) |
|
|
od,face,chamfer (rough machining) |
|
s3000 |
f0.06 |
≈19 |
0.5 |
|
finish machining |
|
s3200 |
f0.07 |
≈6 |
0.5 |
|
drilling |
|
s2000 |
f0.06 |
≈14 |
1 |
|
￠3 drilling |
|
s1600 |
f0.06 |
≈4 |
1 |
|
end milling |
|
s1000 |
f0.03 |
≈6 |
1 |
|
total ≈56s |
|||||
8、precise linear guide-way cnc lathe with slant base body in t-slot blade row : s350
9、cnc lathe sketch:
rigid base
2. parameters, configuration and price:
1) parameters:：
|
main parameters |
unit |
s350 |
||
|
processing capability |
max. swing diameter |
mm |
φ350 |
|
|
max. turning diameter |
mm |
φ240 |
||
|
max. turning length |
mm |
φ340 |
||
|
max. bar through-hole |
mm |
40 |
||
|
spindle |
work piece clamping method |
n/a |
6“hydraulic chuck |
|
|
spindle speed range |
rpm |
0～4500 |
||
|
spindle nose size |
n/a |
a2-5 |
||
|
spindle id |
mm |
52 |
||
|
rapid traverse |
x-axis rapid traverse |
m/min |
20 |
|
|
z-axis rapid traverse |
m/min |
20 |
||
|
axis stroke |
x-axis travel |
mm |
420 |
|
|
z-axis travel |
mm |
400 |
||
|
accuracy |
x\z axis repeating positioning accuracy |
mm |
0.002 |
|
|
motor |
spindle drive motor |
kw |
5.5/7.5 |
|
|
others |
tool-holder type |
n/a |
t-slot blade row |
|
|
tool size |
mm |
20 |
||
|
number of tools |
pcs |
5 |
||
|
required electric power |
kva |
14 |
||
|
overall size(l*w*h) |
mm |
1850*1750*1750 |
||
|
height from floor to spindle center |
mm |
≈1050 |
||
|
net weight |
kg |
≈2500 |
||
|
standard: tool box, instruction book, operational manual, lighting system, lubrication system, chips cleaner, hydraulic collet(chuck), foot switch, high-pressure cooling system
|
||||
|
optional: program control blowing function, precision c axis dividing,spindle head , automatic door, loading and unloading system, industrial robotic,automatic bar feeder, receiving device for bar materials, automatic detection system, automatic cutter radius compensation system, |
|
|||
|
cnc lathe |
||||
|
no. |
item |
component brand & spec. |
original countery |
qty. |
|
1 |
controller |
fanuc mate td |
japan |
1 |
|
2 |
x/z axis servo motor/drive |
fanuc 8nm |
japan |
2 |
|
3 |
spindle motor |
fanuc 5.5/7.5 |
japan |
1 |
|
4 |
ball screw & linear guide-way |
pmi |
taiwan |
2，4 |
|
5 |
spindle bearings |
ntn p4 |
japan |
5 |
|
6 |
spindle structure |
independent spindle with front three bearings and two after |
by gongtie |
1 |
|
7 |
ball screw supporting method |
double supporting with pre-stretching structure |
by gongtie |
1 |
