technique solution
solution ：
1. products processing solution(refer to drawing 378y2)
1) customer: 2) product: 378y2； 3） material: ;
4) the product profile
5) machining accuracy: completely follow up the customer’s drawing;
6) work tool and fixture: 6.1) precision customized 6 inch power chuck
6.2) double quill clamping
7) the technique remarks: the program will set up the tools life-time management (customer pre-set up the q’ty of the machining products, when reach it, automatically warning, for reducing the products scraps and the tools damage.)
8) gongtie company will do the best to provide the technique guidance for cnc lathes and related suggestion of the products processing technology.
|
process |
first process |
second process |
|
operation list |
- turning od(rough finish machining)--grooving
|
- turning od(rough finish machining)--threading(in u type)
|
|
machining benchmark |
with the center hole in two side as the benchmark, axial allocation with double quill |
with the center hole in two side as the benchmark, axial allocation with double quill |
|
work-piece clamping status |
refer to below sketch |
refer to below sketch |
|
sketch (machining) :benchmark face :main clamping |
|
|
|
suitable lathe |
s400 |
s400 |
|
machining cycle time |
58.5s |
52.5s |
|
the workpiece clamping & turning sketch for the first process |
|||||
|
double quill clamping way |
|||||
|
process |
tool |
speed |
feed |
machining time(s) |
|
|
od (rough machining) |
od tool |
1800 |
0.1 |
≈20s |
2.0s |
|
grooving |
groove tool |
1200 |
0.06 |
≈11s |
2.0s |
|
od (rough machining) |
od tool |
2000 |
0.05 |
≈21.5s |
2.0s |
|
the workpiece clamping & turning sketch for the second process |
|||||
|
customized 6 inch pull lock chuck in the outside clamping way |
|||||
|
process |
tool |
speed |
feed |
machining time(s) |
|
|
od (rough machining) |
od tool |
1800 |
0.12 |
≈21.5s |
2.0s |
|
finish machining |
od tool |
2000 |
0.05 |
≈14s |
2.0s |
|
grooving in u type |
customized tool |
1000 |
according to the pitch of the thread |
≈11s |
2.0s |
10) proposal cnc lathe：
precise linear guide-way cnc lathe with slant base body in v-8 turret : s400
11) cnc lathe sketch:
11.1) precise linear guide-way cnc lathe with slant base body in v-8 turret : s400
11.2> rigid base
2. parameters, configuration and price:
1) parameters:
|
main parameters |
unit |
s400 |
|
|
capability |
max. swing diameter |
mm |
400 |
|
max. swing diameter on the slide |
mm |
170 |
|
|
max. turning length |
mm |
340 |
|
|
max. bar through-hole |
mm |
40 |
|
|
axis stroke |
x-axis travel |
mm |
155 |
|
z-axis travel |
mm |
370 |
|
|
tailstock -axis travel |
mm |
258 |
|
|
rapid traverse |
x/z-axis |
m/min |
20 |
|
spindle |
spindle nose size |
n/a |
a2-5, (optional:a2-6) |
|
spindle servo motor power |
kw |
7.5/11 |
|
|
spindle speed range |
rpm |
0～4500 |
|
|
work piece clamping method |
n/a |
6'（8'）hydraulic chuck |
|
|
spindle id |
mm |
52 |
|
|
tailstock |
tailstock sleeve stroke |
mm |
100 |
|
tailstock sleeve diameter |
mm |
φ80 |
|
|
tailstock sleeve boring-hole |
n/a |
mt4 |
|
|
toolholder |
toolholder type |
n/a |
hydraulic(servo)turret v-8 |
|
toolholder center height in radial |
mm |
85 |
|
|
tool size |
mm |
20*20 |
|
|
boring rod diameter |
mm |
25(32) |
|
|
accuracy |
x\z axis repeating postioning accuracy |
mm |
0.002 |
|
others |
cooling motor capacity |
l |
120 |
|
hydraulic box capacity |
l |
60 |
|
|
required electric power |
kva |
15 |
|
|
height from floor to spindle center |
mm |
≈950 |
|
|
overall size(l*w*h) |
mm |
2500*1850*1800 |
|
|
net weight |
kg |
≈2700 |
|
|
standard configuration：tool box, instruction book, operational manual, cooling system , lighting system, lubrication system, chips cleaner, hydraulic collet(chuck), foot switch。 |
|||
|
optional configuration: program control blowing function, precision c axis dividing, power spindle head , automatic door, loading and unloading system, industrial robotic, automatic bar feeder, receiving device for bar materials, automatic detection system, automatic cutter radius compensation system, high-pressure cooling system |
|||
2) configuration
|
cnc lathe |
||||
|
no. |
item |
component brand & spec. |
original countery |
qty. |
|
1 |
controller |
fanuc mate td |
japan |
1 |
|
2 |
x/z axis servo motor/drive |
fanuc 8nm |
japan |
2 |
|
3 |
spindle motor |
fanuc 7.5/11 |
japan |
1 |
|
4 |
ball screw & linear guide-way |
pmi |
taiwan |
2，4 |
contact: echo.y.zhang
fax: 0574-88095075
tel: 86-18057486168
email: zhangyang@cngongtie.cn
add: no.16, gaoya road, jiangshan scientific&technological park, yinzhou, ningbo, zhejiang, china. eu r&d center: reggio emilia, italy
